Static Control (ESD) Flooring

Conductive and dissipative floors built to ANSI/ESD S20.20.

Overview

Why Static Control (ESD) Flooring

Floors for plants where static costs you parts, yield or a safety finding. Built to the band your process actually requires, grounded into building ground, and specified against the standard your auditor holds you to rather than against a colour chart.

  • Conductive under 1.0 x 10⁶ ohms
  • Dissipative 1.0 x 10⁶ to 1.0 x 10⁹ ohms
  • ANSI/ESD S20.20, STM7.1, STM97.1 and STM97.2
  • Copper grounding network tied to building ground

Pittsburgh Epoxy

Static Control (ESD) Flooring

The floorThe footwearThe personBuilding ground

Charge has to leave as a system, not as a floor. That is why ANSI/ESD S20.20 measures the floor, the footwear and the person together, and why a floor can hit its number and still fail.

Scheduling

Can you pour it this week?

Live air and dew point across seven industrial corridors, checked against ASTM D3276. Five degrees of margin over the dew point, held through prep, application and cure, or the floor blushes while it is going off.

Reading conditions over Pittsburgh...

What this is and is not

This reads the air. The standard governs the slab, and concrete lags air by hours, sometimes by most of a day after a cold night. A slab can still be under the dew point while the air above it looks fine. So treat this as your scheduling answer, not your go-ahead: the go-ahead comes off a surface thermometer and a hygrometer at the door on the morning of. Cure windows also move by system, so the product data sheet on your job is what governs.

What Trips People Up

A floor can measure right and still fail the audit

Since the 2014 revision of ANSI/ESD S20.20, hitting the resistance number is only half of it. There is a walking test too, and that is where compliant-looking floors come apart.

The floor on its own

ANSI/ESD STM7.1

Measures the floor and nothing else. This is the number most flooring quotes are written against, and it is the easy half.

The floor, the shoes and the person

less than 1.0 x 10⁹ ohms

Measured to ANSI/ESD STM97.1. Your compliant floor with the wrong footwear is a failing system, which is exactly why the standard stopped allowing a floor-only test.

The walking test

less than 100 volts peak

Peak body voltage to ANSI/ESD STM97.2. A floor can read 3.5 x 10⁷ ohms and still push a walking person past 100 volts.

What the auditor actually measures
  1. 01The floorSTM7.1 measures this alone
  2. 02The footwearpart of the system
  3. 03The personpart of the system
  4. 04Building groundcopper strip, bonded

STM7.1 reaches the floor, and stops there.

STM97.1 and 97.2 reach all four links.

STM97.1 under 1 x 109 ohms, and STM97.2 under 100 volts walking

That is the whole chain, measured together. The floor on its own never settles it.

Specification

The two bands the standard defines

Which one your facility needs is set by what you build and how close your people work to live equipment. If an audit already set it for you, that answer wins.

BandResistanceIn plain numbersTest methodSpecified when
Conductiveless than 1.0 x 10⁶ ohmsunder 1,000,000 ohmsANSI/ESD STM7.1Charge has to leave the floor fast and the operation handles parts that fail at low voltage. Common in electronics assembly and munitions or energetics work.
Static dissipative1.0 x 10⁶ up to less than 1.0 x 10⁹ ohms1,000,000 up to 1,000,000,000 ohmsANSI/ESD STM7.1Charge has to bleed off in a controlled way rather than dump. The usual choice where people work around live equipment and a hard path to ground is a shock risk.
Where the bands sit, in ohms
104105106107108109101010111012

ohms, logarithmic

S20.20 system ceiling, 109 ohmsfloor plus footwear plus person, to STM97.1

  • Conductiveless than 1.0 x 106 ohmsCharge has to leave the floor fast.
  • Static dissipative1.0 x 106 up to less than 1.0 x 109 ohmsCharge bleeds off in a controlled way.
  • Ordinary epoxyfar above 1.0 x 109 ohmsHolds charge instead of moving it to ground.

Since the 2014 revision, resistance on its own is no longer enough. The system has to pass a walking test too. An ordinary epoxy floor is insulative, far above the 1.0 x 109 ceiling. It holds charge rather than moving it, so it is a different build, not a different colour of the same one.

Standards

Every standard on this page, by name

So you can check us rather than take our word for it.

ANSI/ESD S20.20

The ESD control program standard an audited facility is held to.

ANSI/ESD STM7.1

How the resistance of the floor itself gets measured.

ANSI/ESD STM97.1

How the floor, the footwear and the person get measured as one system.

ANSI/ESD STM97.2

The walking test. Peak body voltage a person generates on that system.

ASTM D257

The general DC resistance method the flooring methods descend from.

NFPA 77

Recommended practice on static electricity where ignition is the risk, not part damage.

The floor is one third of it

ConductiveDissipativeOrdinary epoxy

10⁹

Floor, footwear and person measured together as one system, ANSI/ESD STM97.1. Passing the floor on its own proves nothing about the system.

What goes in before the topcoat

Copper grid

A grounding network laid into the build and tied to building ground. It is a different build, not a different colour of the same one.

FAQ

Static Control Questions

Twenty five answers, each one opening with the number, standard or test method it turns on.

Less than 1.0 x 10⁹ ohms for the whole system, measured to ANSI/ESD STM97.1 with a person standing on the floor in their work footwear. The floor on its own gets measured to ANSI/ESD STM7.1. Those are two different tests and passing one does not mean passing the other.
